72 Core Outdoor Optical Cable
72 Core Outdoor Optical Cable

  Request price     Contact us



1. Colored fiber

Coated outside diameter:125.0±0.1um

Optical fiber diameter:242±7um

UV color fiber: Standard chromatogram


2. Tube filling compound(Gel)

3. PBT loose tube

4. Steel wire Central strength member

5. Core filling compound

6. Black PE inner jacket Outside diameter: 8.5±0.2mm

7. Corrugated steel tape

8. Filler

9.Black PE out jacket Outside diameter: 12.8±0.2mm

Parameters of fiber

 Optical fiber type  Unit  SM G652  SM G652D  MM 50/125  MM 62.5/125  MM OM3-300
 Waveband  nm  1310/1550  1310/1550  850/1300  850/1300  850/1300
 Attenuation  dB/km  0.36/0.23  0.36/0.23  3.0/1.0  3.0/1.0  3.0/1.0

Ordering information
