INFORMATION
BD300 Optical Time Domain Reflectometer
has excellent dead zone performance and wide dynamic range. Combined with the visual
fault locator, the OTDR can easily find the breaks, bends, splices, faulty
connectors, and other causes of signal loss.
Learned from the operation mode of tablet
computer and smart mobile phone, BD300 series OTDR has simple operation
interface and Windows-like GUI, and this ensures a short learn curve for the
customer.It is small, lightweight, portable, rugged and durable, and is more suitable
for outdoor environment
Key Features
u Optimized measurement
l For network opening: high
speed test mode
l For network maintenance:
accurate test mode
u Multiple combinations of different dynamic ranges and
wavelengths are available
u Support real-time measurement mode and average measurement mode
u Support line light alarm function and maximize the protection
of the optical device
u The optical module has self-test function, and can automatically
detect its performance and state
u Support Chinese and English input. Have friendly input
interface and mobilephone-like input style
u USB interface can easily transfer data between the device and
the PC
u Portable,
hand-held and high cost-effective
Related Video:
How to operate BAUDCOM mini OTDR?
Applications
ü The installation
and maintenance for AN(access network) optical cables
ü The
installation and maintenance for LAN(local area networks)
ü The
installation and maintenance for FTTX
ü The
installation and maintenance for cable TV networks
ü The
installation and maintenance for APON(optical networks)
ü The
installation and maintenance for private optical fiber networksn Specifications
|
Model
|
BD300
|
|
Wavelength
|
1310nm or 1550nm
|
|
Type of fiber
|
9/125um SM Fiber
|
|
Connector
|
FC、SC/PC
|
|
Dynamic Range
|
22dB
|
|
Pulse Width
|
10ns~ 2.5us，Auto
|
|
Measurement
|
m
|
|
Event blind zone
|
3m
|
|
Attenuation
blind
|
10m
|
|
Range accuracy
|
±（1m+2×10-4×distance）
|
|
VFL
|
≥1mW
|
|
Power Supply
|
3pcs of Dry battery
|
|
Battery Work time
|
≥2000 times measure
|
|
Save Data
|
＞500
|
|
Work Temperature
|
-5~40℃
|
|
Save Temperature
|
-10~60℃
|
|
humidity
|
0~85%（no condensation）
|
|
Net weight
|
300g
|
Ordering information
