INFORMATION
Description
The
BD-S5052 is a new generation Ethernet intelligent access switch. It is mainly
deployed on the IP MAN and intranets, meeting requirements the requirements of
carrying various Ethernet services and accessing the Ethernet.
The
BD-S5052 is a case-shaped device with a chassis of 1U high. It provides 48
10/100/1000Base-TX ports and 4 10G SFP+.
Features
• Conforms to IEEE802.3, 802.3u, 802.3ab, 802.3z
• Provides
48 10/100/1000 Base-TX ports and 4 10G SFP+
• High back-plane bandwidth 176Gbps
• Support
standard IP/ Extend IP / MAC IP / ARP ACL
• IGMP snooping and
IGMP Query mode for Multi-media application
• Port mirror and
bandwidth control
• Supports GVRP
function
• IEEE802.3x Flow
control
• Support Port Based
VLAN / 802 .1Q Tag VLAN
• Support IEEE802.3ad
Port trunk with LACP
• Support Spanning
tree protocol IEEE 802.1d
• Supports IEEE
802.1p class of service
• Support IEEE 802.1x
user authentication
• Support Broadcast
storm filter
• Support DHCP server and client
• Support System
event log
• Support command
line interface management
• Management by
Web/SNMP/Telnet/Console
• Surge
protection for power port and data ports
• EMI
standards complies with FCC, CE class B
Specifications
|
Item
|
Description
|
|
Summarize
|
|
Fixed
port
|
48
10/100/1000Base-TX ports.
4
10G SFP+.
1
Console port.
|
|
LED
Indicators
|
PWR,
PoE, 1000M and Link/Act LED.
|
|
Input
voltage
|
100V～240V AC，50/60Hz
|
|
Power
consumption
|
30W
|
|
Operating
temperature
|
0℃～40℃.
|
|
Storage
temperature
|
-10℃～70℃.
|
|
Relative
humidity
|
20%～85% (non-condensing).
|
|
Thermal
methods
|
Built-in
Noiseless FAN.
|
|
Layer 2 Switching
|
|
Switching
capacity
|
176G
|
|
MAC
address table
|
16K,
Support MAC address table management.
|
|
MAC
Address Binding
|
Support.
|
|
MAC
Address Filtering
|
Support.
|
|
MAC
Address Learning control
|
Control
number of port-based MAC address learning.
|
|
Jumbo
Frame
|
Jumbo
packets up to 16 Kbytes.
|
|
Port
Feature
|
Port
Control.
Port
Isolation.
Port
Self-loop Detection.
|
|
Port
Mirroring
|
Support.
|
|
VLAN
|
4K
802.1q VLANs, Support Ingress filter.
|
|
Link
Aggregation
|
Up
to 32 maximum aggregation groups, each containing up to 8 GE ports.
|
|
Traffic
control
|
IEEE
802.3x full-duplex flow control.
|
|
Rate
Limit
|
Unit:
64kbps.
|
|
Spanning
Tree
|
IEEE
802.1d Spanning Tree Protocol (STP)
IEEE
802.1w Rapid Spanning Tree Protocol (RSTP)
IEEE
802.1s Multiple Spanning Tree Protocol (MSTP)
|
|
Ring
Protocol
|
Support
EAPS.
|
|
Multicast
|
Support
1K Multicast groups.
Support
IGMP Snooping.
|
|
Layer 3 Switching
|
|
Static
ARP
|
Support.
|
|
Static
Routing
|
Support.
|
|
L3
VLAN interface
|
Up
to 32 L3 VLAN Interface (support 128 MAC).
|
|
Convergence
|
|
QoS
|
4 output queues
on each port.
Support flexible
queue scheduling algorithms: WRR，SP，DRR，RR.
Support MAC-based
/ 802.1p / DiffServ classification.
|
|
Security
|
|
ACL
|
Support
Standard IP / Extend IP / MAC IP / ARP
Support
1024 entries
|
|
Security
Features
|
Support
MAC-based 802.1X authentication.
Support
AAA/RADIUS authentication.
Support
WEB/Telnet password protection.
Support
Accessing privilege mode password protection.
|
|
Self-protection
|
Support
CPU Self-protection.
|
|
Management
|
|
CLI
|
Support
CLI (Commend Line Interface) configuration mode.
|
|
Console
|
Support
Configuration via the console port.
|
|
Telnet
|
Support
Local/remote configuration via Telnet.
|
|
WEB
|
Support
WEB management system.
|
|
SNMP
|
Support
System configuration with SNMP v1/v2/v3.
|
|
User
Management
|
Support
Multi-user management.
|
|
System
Log
|
Support.
|
|
Configuration
File Download/Upload
|
Support
Download/Upload configuration File via WEB/TFTP.
|
|
Upgrade
Firmware
|
Support
Upgrade Firmware via WEB/TFTP/Console.
|
|
Debug
|
|
PING
|
Support.
|
|
TRACEROUTE
|
Support.
|
|
Telnet
client
|
Support.
|
|
Process
View
|
Support.
|
