16GB FC SFP Features
➢ Supports up to 14.025Gbps bit rates
➢ Hot-pluggable SFP+ footprint
➢ 50GHz ITU, C-Band & H-Band DWDM Cooled EML laser and PIN photodiode, Up to 40km for SMF transmission
➢ Compliant with SFP+ MSA and SFF-8472 with duplex LC receptacle
➢ Compatible with RoHS
➢ Single +3.3V power supply
➢ Real Time Digital Diagnostic Monitoring
➢ Operating case temperature Standard: 0 to +70°C
Optical transceiver modules Applications
➢ 4.25/8.5/14.025G Fibre channel
➢ Other Optical links
Optical and Electrical Characteristics
Parameter
|
Symbol
|
Min
|
Typical
|
Max
|
Unit
|
Notes
|
Transmitter
|
Centre Wavelength
|
λc
|
As per ITU-T 694.1
|
nm
|
|
Centre Wavelength(EOL)
|
λc_EOL
|
λc±100pm
|
nm
|
|
Spectral Width（-20dB）
|
Δλ
|
|
|
1
|
nm
|
|
Side-Mode Suppression Ratio
|
SMSR
|
30
|
-
|
|
dB
|
|
Average Output Power
|
Pout
|
-1
|
|
+3
|
dBm
|
1
|
Extinction Ratio
|
ER
|
6.0
|
|
|
dB
|
|
Data Input Swing Differential
|
VIN
|
180
|
|
850
|
mV
|
2
|
Input Differential Impedance
|
ZIN
|
90
|
100
|
110
|
Ω
|
|
TX Disable
|
Disable
|
|
2.0
|
|
Vcc
|
V
|
|
Enable
|
|
0
|
|
0.8
|
V
|
|
TX Fault
|
Fault
|
|
2.0
|
|
Vcc
|
V
|
|
Normal
|
|
0
|
|
0.8
|
V
|
|
Receiver
|
Centre Wavelength
|
λc
|
1450
|
|
1620
|
nm
|
|
Receiver Sensitivity
|
|
|
|
-14
|
dBm
|
3
|
Receiver Overload
|
|
0.5
|
|
|
dBm
|
3
|
LOS De-Assert
|
LOSD
|
|
|
-15
|
dBm
|
|
LOS Assert
|
LOSA
|
-28
|
|
|
dBm
|
|
LOS Hysteresis
|
|
0.5
|
|
|
dB
|
|
Data Output Swing Differential
|
Vout
|
300
|
|
900
|
mV
|
4
|
LOS
|
High
|
2.0
|
|
Vcc
|
V
|
|
Low
|
|
|
0.8
|
V
|
|
16GB FC SFP Notes:
1. The optical power is launched into SMF.
2. PECL input, internally AC-coupled and terminated.
3. Measured with a PRBS 231-1 test pattern @14025Mbps, BER ≤1×10-12.
4. Internally AC-coupled.
λC Wavelength Guide(C-Band)
|
ITU Channel
Product Code
|
Frequency(THz)
|
Wavelength
|
ITU Channel
Product Code
|
Frequency(THz)
|
Wavelength
|
|
|
|
40
|
194.00
|
1545.32
|
|
|
|
41
|
194.10
|
1544.53
|
|
|
|
42
|
194.20
|
1543.73
|
20
|
192.00
|
1561.42
|
43
|
194.30
|
1542.94
|
21
|
192.10
|
1560.61
|
44
|
194.40
|
1542.14
|
22
|
192.20
|
1559.79
|
45
|
194.50
|
1541.35
|
23
|
192.30
|
1558.98
|
46
|
194.60
|
1540.56
|
24
|
192.40
|
1558.17
|
47
|
194.70
|
1539.77
|
25
|
192.50
|
1557.36
|
48
|
194.80
|
1538.98
|
26
|
192.60
|
1556.55
|
49
|
194.90
|
1538.19
|
27
|
192.70
|
1555.75
|
50
|
195.00
|
1537.40
|
28
|
192.80
|
1554.94
|
51
|
195.10
|
1536.61
|
29
|
192.90
|
1554.13
|
52
|
195.20
|
1535.82
|
30
|
193.00
|
1553.33
|
53
|
195.30
|
1535.04
|
31
|
193.10
|
1552.52
|
54
|
195.40
|
1534.25
|
32
|
193.20
|
1551.72
|
55
|
195.50
|
1533.47
|
33
|
193.30
|
1550.92
|
56
|
195.60
|
1532.68
|
34
|
193.40
|
1550.12
|
57
|
195.70
|
1531.90
|
35
|
193.50
|
1549.32
|
58
|
195.80
|
1531.12
|
36
|
193.60
|
1548.51
|
59
|
195.90
|
1530.33
|
37
|
193.70
|
1547.72
|
60
|
196.00
|
1529.55
|
38
|
193.80
|
1546.92
|
61
|
196.10
|
1528.77
|
39
|
193.90
|
1546.12
|
-
|
-
|
-
|
λC Wavelength Guide(H-Band)
|
ITU Channel
Product Code
|
Frequency(THz)
|
Wavelength
|
ITU Channel
Product Code
|
Frequency(THz)
|
Wavelength
|
|
|
|
40
|
194.05
|
1544.92
|
|
|
|
41
|
194.15
|
1544.13
|
|
|
|
42
|
194.25
|
1543.33
|
20
|
192.05
|
1561.03
|
43
|
194.35
|
1542.54
|
21
|
192.15
|
1560.20
|
44
|
194.45
|
1541.75
|
22
|
192.25
|
1559.39
|
45
|
194.55
|
1540.95
|
23
|
192.35
|
1558.58
|
46
|
194.65
|
1540.16
|
24
|
192.45
|
1557.77
|
47
|
194.75
|
1539.37
|
25
|
192.55
|
1556.96
|
48
|
194.85
|
1538.58
|
26
|
192.65
|
1556.15
|
49
|
194.95
|
1537.79
|
27
|
192.75
|
1555.34
|
50
|
195.05
|
1537.00
|
28
|
192.85
|
1554.54
|
51
|
195.15
|
1536.22
|
29
|
192.95
|
1553.73
|
52
|
195.25
|
1535.43
|
30
|
193.05
|
1552.93
|
53
|
195.35
|
1534.64
|
31
|
193.15
|
1552.12
|
54
|
195.45
|
1533.86
|
32
|
193.25
|
1551.32
|
55
|
195.55
|
1533.07
|
33
|
193.35
|
1550.52
|
56
|
195.65
|
1532.29
|
34
|
193.45
|
1549.72
|
57
|
195.75
|
1531.51
|
35
|
193.55
|
1548.91
|
58
|
195.85
|
1530.72
|
36
|
193.65
|
1548.11
|
59
|
195.95
|
1529.94
|
37
|
193.75
|
1547.32
|
60
|
196.05
|
1529.16
|
38
|
193.85
|
1546.52
|
61
|
196.15
|
1528.38
|
39
|
193.95
|
1545.72
|
-
|
-
|
-
|
