INFORMATION
Description
6x 10/100M RJ45 ports for
connecting with devices like computer, switch, hub, server, etc, as well as
powering network camera, VoIP, wireless AP and other devices. Optical fiber SFP
interface extends network transmission distance limit from 100m to above 120KM,
it simply connects remote multiple motherboard servers, relays, hubs, terminals
and multiple terminals.
BD-S106FI product components were rigorous
screened, have superior performance in stability, environmental adaptability.
Shells were made by aluminum extrusion, more lighter, stronger, better resistance
ability to corrosion and electromagnetic
interference, ensure stability and security of Industrial Ethernet Switch, plus standard DIN-35 rail type installation
method. Power input also chooses a suitable industry-standard types of
power, to get more powerful suitability
to environment.
Specifications
|
Product Name
|
6FE
industrial fiber switch
|
|
Product Model
|
BD-S106FI
|
|
Interface
|
6x 10/100M RJ45 Ports
|
|
Forwarding Mode
|
Store-and-forward
|
|
Optical Port Transmission Distance
|
120km, 1310nm, depend on
optical module you used
|
|
Performance Specification
|
Bandwidth: 1.8Gbps
Buffer:1M
SRAM Buffer: 448Kbits
Forwarding Rate:1.19Mbps@64byts
Mac Address Table: 1K
MTBF: 539608 hours
|
|
Standards Compliance
|
IEEE802.1P
IEEE802.1q
IEEE802.3az
|
|
LED Indicators
|
RJ45 Port:Link/Act, SPD
Optical Port: Link/Act
|
|
Power
|
5.08mm 5-pin industrial terminal
block
Input voltage:DC12~48V
|
|
Product Size
|
W×D×H:
128*105*54mm
|
|
Working Environment
|
Working Temperature: -40～80℃
Storage Temperature: -40～85℃
Working Humidity: 5%～95%（non-condensing）
Storage Humidity: 5%～95%（non-condensing）
Working high: Altitude of 3000 m（10,000ft）
Storage high: Altitude of 3000 m（10,000ft）
|
|
Radiation
|
CE mark, commercial
FCC Part 15 Class B
VCCI Class B
EN 55022 （CISPR 22）,
Class B
|
|
Safety
|
CE Mark, commercial
CE/LVD EN60950
|
|
Warranty
|
5 years warranty
|
Dimension
